HY-R17 automatic fan motor winding machine Details
HY-R17 automatic fan motor winding machine
Automatic fan motor winding machine - Features:
a. teach touch interactive, user-friendly interface, easy handling, the cultural program management, easy to learn, five minutes to get started, no keyboard and an external power supply, input, machine time is short
b. The use CNC 4 + 1 axis AC servo motor, fast positioning, high accuracy
c. quick change independent Winding the rule.
d. Rotary feeding and discharging mechanism, increase productivity
e. precise tension control, quality and security
f. automatic processing lines, leaving more than line
g. can be wrapped around any angle foot, high adaptability
h. unique transmission structure, high rigidity machine movement
Automatic fan motor winding machine - Specifications:
Power supply voltage three-phase AC 220V ± 10% 50HZ / 60HZ
Power consumption 5KVA
The control method CNC 4 + 1 axis AC servo motor synchronization control
4-axis spindles
Max 6000RPM spindle speed
Spindle pitch (mm) 120mm
Spindle positioning angle 0 - 360 ° / rev
Setting unit 1 °
Displacement accuracy 0.01mm
Spindle positioning accuracy of ± 1 °
Use diameter 0.02-0.3mm
Foot-Speed MAX: 150RPM
The maximum roll diameter 45mm
The maximum stack thickness 40mm
Storage mnemonics USB + DOM64M (256M option)
Use air pressure 4-6kgf / cm2
Machine net weight (kg) 380kg
Mechanical weight after packing (kg) 450kg
Machine Size (mm) 1100L * 1090W * 1310H mm
Mechanical Packing size (mm) 1210L * 1190W * 1410H mm
